Pico Single Channel Relay HAT

Pico Single Channel Relay HAT is a single channel High-quality relay with loads up to 250V AC/ 7 A, 30V DC/ 10A to provide a way to control the high voltage/current devices. It comes with a Female Pin Header, to easily connect with Raspberry Pi Pico via effortless stacking. It is designed to be compatible with Raspberry Pi Pico which enhances the utilization of Raspberry Pi Pico with the combination of the relay. High-quality components with powerful OptoIsolated output make the Pico Single channel relay more reliable and efficient to use in projects.

The design and look of the Pico Single Channel Relay are compact with clear pin labeling and additional functional information that make the utilization of the product quite easy for the users.

Features:

• High-Quality Relay: Capable of handling loads up to 7A at 250 VAC and 15A at 120 VAC.
• Switching Voltage: Supports switching voltages up to 10A at 250V AC and 10A at 30V DC.
• Optocoupler Isolation: Ensures safe and reliable operation by isolating the control circuit from the high-voltage load.
• Compact Design: Designed to fit seamlessly with the Raspberry Pi Pico, maintaining a small footprint for embedded projects.

Specifications:

• Relay Load Capacity:

  • • 7A at 250 VAC

    • 15A at 120 VAC

• Switching Voltage:

  • • 10A at 250V AC

    • 10A at 30V DC

• Control Pin: Utilizes GPIO pin GP6 on the Raspberry Pi Pico for relay control.
• Dimensions: Compact form factor matching the Raspberry Pi Pico's design.

Kit Content

• 1 x Pico Single Channel Relay HAT Board Only.
