ROCK S0 512MB with Wi-Fi 4 / BT5

Meet the ROCK S0 – your go-to Single Board Computer (SBC) for when you need hardware that packs a punch in an ultra-compact form factor. This little powerhouse offers class-leading performance thanks to the awesome Rockchip RK3308BS SoC, which fits into your projects with ease.

Key features of the Radxa ROCK S0 Single Board Computer

ROCK-Solid Performance
Powered by a reliable Rockchip RK3308BS SoC and a Quad-core ARM Cortex-A35 CPU, this SBC ensures top-notch performance – because who doesn’t want their board to ROCK?

Stay Connected
The onboard Wi-Fi brings you 802.11 b/g/n Wireless LAN (WiFi4) and BT5 with BLE capabilities. Need a wired connection? No problem – there’s a 10/100 Mbit Ethernet connection for that.
Operating System Freedom
This little board plays nice with various operating systems, including ARMv8 Instruction Set, Debian/Ubuntu Linux support, and a Hardware access/control library for Linux. More OS means more options to tinker with

Endless Connectivity
The 40-pin GPIO expansion header opens a world of possibilities, supporting a plethora of interface options. Your Radxa ROCK S0 works seamlessly with a ton of SBC accessories, ensuring you’re never short on connectivity.

Interfaces

• 1 x USB2.0 OTG via 4‑Pin MX 1.25mm connector
• 1 x USB2.0 HOST via 4‑Pin MX 1.25mm connector
• 1 x Maskrom key
• 1 x Reset key
• 1 x 100M Ethernet RJ45 via 4Pin MX 1.25mm connector
• 1 x TF Card Slot
• 40-pin GPIO Header (I2C x4, PWM x3, SPI x2, UART x3, I2S0 x1, 5V DC power in x2, 3.3V DC power in x2)

Technical Specifications
