Radxa X2L 4GB Single Board Computer

Meet the Radxa X2L featuring the Intel J4125 processor – your go-to single-board computer (SBC) for a seamless blend of power and affordability. Whether you’re boosting office productivity, diving into multimedia projects,...

RAM: 4GB

4GB
8GB
Description

Meet the Radxa X2L featuring the Intel J4125 processor – your go-to single-board computer (SBC) for a seamless blend of power and affordability. Whether you’re boosting office productivity, diving into multimedia projects, or setting up a small server, this compact and portable SBC has you covered.

Why go for the Radxa X2L SBC?

Versatile Performance
The Intel J4125 processor powers the Radxa X2L, delivering top-notch performance across a range of applications, from office tasks to immersive entertainment and multitasking.

Effortless Networking
Thanks to the RTL8111H controller, you get Gigabit Ethernet connectivity that’s both fast and energy-efficient, perfect for high-speed networking.

Double the Display Fun
With HDMI interfaces supporting up to 4Kp30 resolution, you can set up dual displays for increased productivity or enjoy entertainment on a variety of compatible devices.

Connectivity Galore
Two USB 2.0 and two USB 3.0 Type-A ports make connecting peripherals a breeze, ensuring speedy data transfer with USB 3.0 devices.

OS Freedom
The Radxa X2L gives you the freedom to pick your OS, working smoothly with Intel® 64 Instruction Set, Windows 10 64-bit, and supporting Debian/Ubuntu Linux. It’s not just about choice; this SBC also comes with a handy hardware access/control library for Linux, making things easy for developers and enthusiasts alike.

Swift Storage Solutions
The M.2 M Key connector supports PCIe 2.0 for M.2 NVMe SSDs, enabling direct OS boot for quicker startups and efficient system performance.

Go Wireless
The M.2 E Key connector supports PCIe 2.0 signals and USB connectivity, making adding wireless modules for both WiFi and Bluetooth hassle-free.

GPIO Expansion Header
The 40-pin GPIO expansion header opens up a world of interface options, giving you the flexibility you need.

Adaptable to Almost Any Situation
Designed to handle temperatures from 0°C to 50°C, the Radxa X2L, powered by the Intel J4125 processor, keeps things cool while delivering a responsive user experience in various computing scenarios.

Interfaces:

  • Dual Display Outputs via Two HDMI up to 4Kp30
  • 1 x Gigabit Ethernet
  • 1 x M.2 E Key Connector for WiFi / BT Module
  • 1 x M.2 M Key Connector for M.2 NVMe SSD for OS Boot and Storage
  • 2 x USB 2.0 HOST Type A Port
  • 2 x USB 3.0 HOST Type A Port
  • 1 x RTC Battery Socket
  • 1 x 3.5mm Headphone Jack with Microphone Input
  • 1 x 4‑Pin 1.25mm Fan Header
  • 1 x 3‑Pin Debug Header
  • 4 x Buttons (1x Power Button – 1x BOOTSEL Button for RP2040, 1x User Button, 1x Clear CMOS Button)
  • 40‑Pin GPIO Header supporting a wide range of interface options: Up to 2x SPI, Up to 2x UART, Up to 2x I2C, Up to 16x PWM, Up to 8 × PIO (Programmable IO), 1 x 5V DC power in/out, 2 x 3.3V power out

Technical Specifications

Processor Intel® Celeron® Processor J4125
GPU Intel® UHD Graphics 600
Memory 4GB/8GB LPDDR4 RAM up to 2400 MT/s
Power Requirements The Radxa X2L supports the following power input: USB Type‑C PD Version 2.0 with 9V/2A, 12V/2A, 15V/2A and 20V/2A or Power adapter with fixed voltage in 9V to 20V range on the USB Type‑C port
HDMI Dual HDMI ports supporting displays up to 4Kp60 resolution
USB 2x USB 2.0 HOST Type A Port, 2x USB 3.0 HOST Type A Port
Storage M.2 M Key Connector for M.2 NVMe SSD
UARTS Up to 2x UART
On/Off Power Button YES
Software Intel® 64 Instruction Set, Windows 10 64‑bit,Debian / Ubuntu Linux support, Hardware access/control library for Linux
Operating Temperature 0∼50 ℃
Box Content

  • 1 x Radxa X2L 4GB/8GB Board
