ROCK S0 512MB with Wi-Fi 4 / BT5

Meet the ROCK S0 – your go-to Single Board Computer (SBC) for when you need hardware that packs a punch in an ultra-compact form factor. This little powerhouse offers class-leading performance thanks...

Description

Meet the ROCK S0 – your go-to Single Board Computer (SBC) for when you need hardware that packs a punch in an ultra-compact form factor. This little powerhouse offers class-leading performance thanks to the awesome Rockchip RK3308BS SoC, which fits into your projects with ease.

Key features of the Radxa ROCK S0 Single Board Computer

ROCK-Solid Performance
Powered by a reliable Rockchip RK3308BS SoC and a Quad-core ARM Cortex-A35 CPU, this SBC ensures top-notch performance – because who doesn’t want their board to ROCK?

Stay Connected
The onboard Wi-Fi brings you 802.11 b/g/n Wireless LAN (WiFi4) and BT5 with BLE capabilities. Need a wired connection? No problem – there’s a 10/100 Mbit Ethernet connection for that.
Operating System Freedom
This little board plays nice with various operating systems, including ARMv8 Instruction Set, Debian/Ubuntu Linux support, and a Hardware access/control library for Linux. More OS means more options to tinker with

Endless Connectivity
The 40-pin GPIO expansion header opens a world of possibilities, supporting a plethora of interface options. Your Radxa ROCK S0 works seamlessly with a ton of SBC accessories, ensuring you’re never short on connectivity.

Interfaces

  • 1 x USB2.0 OTG via 4‑Pin MX 1.25mm connector
  • 1 x USB2.0 HOST via 4‑Pin MX 1.25mm connector
  • 1 x Maskrom key
  • 1 x Reset key
  • 1 x 100M Ethernet RJ45 via 4Pin MX 1.25mm connector
  • 1 x TF Card Slot
  • 40-pin GPIO Header (I2C x4, PWM x3, SPI x2, UART x3, I2S0 x1, 5V DC power in x2, 3.3V DC power in x2)

Technical Specifications

SoC Rockchip RK3308BS
Processor Quad Cortex‑A35 ARM 64bits processor frequency up to 1.3GHz
RAM 512MB DDR3
Storage TF Card Slot
Wireless Module Wi-Fi 4 / BT 5.0 with BLE
USB

1 x USB2.0 OTG via 4-Pin MX 1.25mm connector for Power and Data

1 x USB2.0 HOST via 4-Pin MX 1.25mm connector

Ethernet 1 x 100M Ethernet RJ45 via 4Pin MX 1.25mm connector
IO 40-pin GPIO Header
Power 1 x USB2.0 OTG via 4-Pin MX 1.25mm connector for Power and Data
Software

ARMv8 Instruction Set

Debian/Ubuntu Linux support

Hardware access/control library for Linux

Form Factor 65mm x 30mm
Temperature Operation temperature: 0~50 ℃
Box Content

  • 1 x ROCK S0 512MB
