2.1mm DC Power Jack with Rocker Switch

This brilliant invention is a blessing for makers designing or using boards with standard 2.1mm DC barrel jacks. Many devices opt against a proper power switch, for size or cost or other design reasons. So, you're expected to unplug when not in use. But you want something a little fancier! This 2.1mm DC Power Jack with Rocker Switch has the same PCB layout as classic non-switched jacks but has a li'l extra on top - a labeled slide switch!

The slide switch does exactly what you'd expect: plug in your power supply (up to 16 VDC, 3A) and switch power on and off. On and off! On and off all day. You can clicky-clack to your maker heart's delight! We swear we're not pulling your lead--I mean, leg, this has a seriously satisfying clack.

We also have a version with a slide switch here.

Features:

• Electrical Rating: 15VDC 2.5A
• Contact Resistance: < 20 mΩ (initial)
• Insulation Resistance: > 1000 MΩ @ 500VDC
• Dielectric Strength: > 1500V @ 1 min.
• Life: 6,000 cycles
• Contact material: Copper alloy with silver plating
• Switch Circuit: SPDT
• RoHS compliant: Yes
• Product Dimensions: 28.0mm x 16.8mm x 8.9mm / 1.1" x 0.7" x 0.4"
• Product Weight: 3.0g / 0.1oz
