Adafruit Metro M4 Express AirLift (WiFi) - Lite

Elevate your next project with the Adafruit Metro M4 AirLift—a powerful microcontroller board that combines the speed and capabilities of the ATSAMD51 with the wireless power of the ESP32 co-processor. This versatile board offers all the features you love about the Metro M4, with added WiFi connectivity for easy IoT integration, making it ideal for wireless projects.

Key Features:

• ATSAMD51 Microcontroller:
  • 120 MHz Cortex-M4 core with floating-point support.
  • 512 KB Flash, 192 KB RAM for fast and spacious performance.
  • Built-in crypto engines with AES (256-bit encryption), true RNG, and Pubkey controller.
• AirLift WiFi Co-processor:
  • Certified WiFi module with TLS/SSL support, pre-loaded root certificates.
  • Communication via SPI and ready-to-use Arduino and CircuitPython libraries for quick wireless integration.
• Dual Analog/Digital Conversion:
  • 2 x 1 MSPS DAC and 2 x 1 MSPS ADC for precise analog signal processing.
  • Stereo I2S input/output with MCK pin for audio.
• Expanded I/O:
  • 25 GPIO pins, with 8 analog inputs, and 2 analog outputs.
  • 6 x SERCOM interfaces (I2C, SPI, or UART).
  • 22 PWM outputs for versatile control options.
• Native USB Support: No need for an external USB-to-serial converter. Acts as a serial device or can function as an HID keyboard/mouse.
• Built-in 2MB Flash Storage: Acts as a tiny hard drive for storing scripts, libraries, and files in CircuitPython or for use in Arduino for datalogging.
• Power Flexibility: Powered by 7-9V DC (via 2.1mm DC jack) or 5V USB. Includes an on/off switch for easy control and automatic switching between USB and DC power.
• Easy Programming: Pre-loaded with the UF2 bootloader for easy drag-and-drop firmware updates. Compatible with CircuitPython and Arduino IDE.

Extra Features:

• Four indicator LEDs (green power LED, two RX/TX LEDs for USB data, and a red LED).
• RGB NeoPixel for custom use or debugging.
• USB-to-Serial: For easy access to your microcontroller from any computer for communication or updates.

The Metro M4 AirLift is perfect for creating secure IoT projects, and with CircuitPython running smoothly at 120 MHz, it’s a breeze to get started. Whether you’re creating a smart device, a connected sensor, or a wireless controller, this board has the power, flexibility, and wireless capability you need to bring your ideas to life. Get your hands on a Metro M4 AirLift today and experience how easy and fast it is to work with IoT projects!
